1239ZDF

12mm Sonic vibration motor

Diameter: 12.5mm; Length: 39mm; Voltage: 3.7v; Vibration frequency: 36000/40800 times; Lifespan: 2000H;

Production plant: Shenzhen Guangming Factory, Chongqing Fuling Factory.

Applications:electric toothbrush, health care equipment, cleaning equipment, etc.

Customizable options: gauge, lead length, shaft length, performance.

Unit price: Quote according to customer quantity and solution requirements

Nombre	Unidad	1239ZDF-ET-L2-33-3.7	1239ZDF-ET-L4-3.7	1239ZDF-1-L8-3.7
Voltage	V	3.7	3.7	3.7
Resistance	Ω	5.3	4.0	4.0
Operating frequency range	Hz	180~350	180~350	180~350
No-load vibration frequency	Times/minute	40800	36000	36000
No-load current	mA	130	140	140
Starting torque	mNm	11	11	11
Starting current	A	0.8	0.9	0.9
Rated load (Brush head)	g	3.8	3.8	3.8
Load vibration frequency	Times/minute	30000	30000	30000
Load current	mA	320	400	350
Rotor inertia	gcm²	0.65	0.65	0.65
Weight	g	16.8	16.7	16.7
Operating temperature range	°C	-10～+60	-10～+60	-10～+60
