L8.520N7M

Applications: mini UAV’s, remote control hobby products, small household appliances, etc.

Customizable options: Specifications, wire length, shaft length, performance, gearbox.

Unit price: Quote based on customer quantity and solution requirements

应用领域：微型无人机、智能电玩、小家电产品等领域。

可定制选项: 规格，导线长度，轴长，性能，齿轮箱。

单价: 根据客户数量、方案要求报价

Nombre	Unidad	11-240-3.0	01-300-7.0	02-200-3.0
Voltage	V	3.0	7.0	3.0
Terminal resistance	Ω	0.83	2.3	0.37
No-load speed	rpm	23650	30300	39000
No-load current	mA	90	70	70
Stall torque	mNm	4.2	6.4	5.9
Stall current	mA	3610	3040	8110
Load torque	mNm	0.5	1	1
Load speed	rpm	20810	25570	32340
Load current	mA	510	530	1440
Max.output power	W	2.58	5.1	6
Max.efficiency	%	71.1	72	82
Back-EMF constant	mV/rpm	0.12	0.2	0.08
Torque constant	mNm/A	1.18	2.2	0.73
Speed/torque gradient	rpm/mNm	5681	4730	6660
Weight	g	4.87	5	4.9
Rotor inertia	gcm²	0.07	0.8	0.8
Operating temperature range	°C	-20～+80	-20～+80	-20～+80
