C2025F

20mm DC iron core motor

Diameter: 20.3mm; Length: 25mm; Voltage: 12.0v; No-load speed: 11420rpm; Load torque: 1.96mNm; Maximum output power: 2.7W.

Application areas: small electronic products, portable tools, smart door locks, etc.

Customizable options: specifications, wire length, shaft length, performance, gearbox.

Unit price: Quote based on customer quantity and solution requirements

Nombre	Unidad	41-0175
Voltage	V	12.0
No-load speed	rpm	11420
No-load current	mA	62
Stall torque	mNm	9.1
Stall current	mA	950
Load torque	mNm	1.96
Load speed	rpm	8971
Load current	mA	250
Max output power	W	2.7
Max efficiency	%	60.6
Torque constant	mNm/A	10.3
Speed/torque gradient	rpm/mNm	1255
Weight	g	25
Varistor	Yes/No	Yes
Operating temperature range	°C	0～+60
